Dualsky DSXM51669 ECO 3520C 1020kv Brushless Motor
The 3520C ECO motor from Dualsky has 1020Kv of power. This motor comes with propeller and motor mounts, in addition to gold plugs and screws.
Features
- High strength, rust proof main shaft
- Waterproof (ball bearing not waterproof)
- High purity copper wire and temperature can reach 180oC
- Electromagnetic design
- Optimised stress distribution and strength increased without increasing the weight
Specification
- KV: 1020
- Turns: 4
- Weight: 210g
- Dimensions: 43.2 x 42.4mm
- Slots & Poles: 12N14P
- Ri (mOhm): 10.8
- Io@10V: 2.6
- No. of cells: 3..4
- Max. Efficiency Current [A]: 48
- Max. Burst Current (15S) [A]: 80
- Max. Power (15S)[A]: 960
- Max. Torque [N*M]: 0.9
- Shaft diameter: 6mm
- Mounting holes pitch: 25/25
- Input Connectors: GC4.0
- Recommended ESC: XC8018BA
- Propeller: 3S: 14x7E, 13x6.5E / 4S: 11x535E, 10x5E:
- Class: .50 4-Stroke .32-.0 (40E) 2-Stroke
$25.95
Original: $74.14
-65%Dualsky DSXM51669 ECO 3520C 1020kv Brushless Motor—
$74.14
$25.95Dualsky DSXM51669 ECO 3520C 1020kv Brushless Motor
The 3520C ECO motor from Dualsky has 1020Kv of power. This motor comes with propeller and motor mounts, in addition to gold plugs and screws.
Features
- High strength, rust proof main shaft
- Waterproof (ball bearing not waterproof)
- High purity copper wire and temperature can reach 180oC
- Electromagnetic design
- Optimised stress distribution and strength increased without increasing the weight
Specification
- KV: 1020
- Turns: 4
- Weight: 210g
- Dimensions: 43.2 x 42.4mm
- Slots & Poles: 12N14P
- Ri (mOhm): 10.8
- Io@10V: 2.6
- No. of cells: 3..4
- Max. Efficiency Current [A]: 48
- Max. Burst Current (15S) [A]: 80
- Max. Power (15S)[A]: 960
- Max. Torque [N*M]: 0.9
- Shaft diameter: 6mm
- Mounting holes pitch: 25/25
- Input Connectors: GC4.0
- Recommended ESC: XC8018BA
- Propeller: 3S: 14x7E, 13x6.5E / 4S: 11x535E, 10x5E:
- Class: .50 4-Stroke .32-.0 (40E) 2-Stroke
